Overview
Configurations
videos
Overview
RhinoCAM
RhinoCAM is a CAM Software plug-in that runs completely inside of Rhinoceros 6.0 & 7.0 (Windows only).
RhinoCAM marries the power of Rhino’s freeform modeling with the legendary CAM functionality of VisualCAM to bring you a product of unrivaled capability.
With seamless and complete integration RhinoCAM, acts and feels like you are working with Rhino when generating CNC programs. RhinoCAM is also fully associative to any geometry changes within Rhino.
RhinoCAM includes modules for MILL, TURN, NEST, MESH & ART
Configurations
Configurations
RhinoCAM CAM software comes in 5 different configurations to suit the varied machining needs of our customers.
RhinoCAM Xpress (XPR)
This is a general purpose program tailored for hobbyists, makers and students. Ideal for getting started with CAM programming. Includes 2 & 3 axis machining methods. Packed with sufficiently powerful manufacturing methods this easy to use package is not only effective but also attractively priced for the budget conscious or entry level buyer. This module includes the NEST and ART free of cost.
RhinoCAM Standard (STD)
This is a general purpose machining program targeted at the general machinist. This product is ideal for the rapid-prototyping, hobby and educational markets where ease of use is a paramount requirement. Includes 2-1/2 Axis, 3 Axis and Drilling machining methods. This module includes the TURN, NEST and ART free of cost.
RhinoCAM Expert (EXP)
This configuration allows 4th Axis Indexed and continuous roughing and finishing operations to be created. Curve based continuous machining such as 4 Axis Facing, Pocketing, Profiling & Engraving as well as Surface/solids/meshes based machining such as Roughing, Finishing and Curve Projection machining are available. This configuration includes all of the functionality included in the STD configuration. This module includes the TURN, NEST and ART free of cost.
RhinoCAM Professional (PRO)
This powerful package is ideal for mold, die and tooling, wood working rapid-prototyping and general machining markets. This product boasts of powerful toolpath generation strategies coupled with tools for efficiently controlling the cutting tool for detailed machining capabilities, while not sacrificing ease of use. Suitable for demanding users with sophisticated manufacturing requirements. This product configuration includes all of the functionality included in the EXP configuration described above. This module includes the TURN, NEST and ART free of cost.
RhinoCAM Premium (PRE)
This package includes our new 5 Axis continuous machining functionality. Suitable for highly sophisticated machining requirements such as aerospace, advanced mold making and woodworking industry, this package includes such machining methods such as surface normal machining, swarf machining and surface flow machining. The package in addition includes all the functionality found in the PRO configuration described above. This module includes the TURN, NEST and ART free of cost.
videos
Videos
-
RhinoCAM 2023 TURN Quick Start
Watch this video to get a quick start using the TURN Module included in RhinoCAM 2023. You will learn how to set up a turn part, stock definition, turn roughing, turn finishing, simulation, post processing and shop docs! (Get more resources at www.mecsoft.com)!
Download your FREE demo here – mecsoft.com/downloads/demos/
Get more information about MecSoft CAM products here:
VisualCAD/CAM: https://mecsoft.com/visualcadcam/
RhinoCAM: https://mecsoft.com/rhinocam/
Check out MecSoft’s CAM solutions here:
MILL: https://mecsoft.com/milling-software/
TURN: https://mecsoft.com/turn/
NEST: https://mecsoft.com/nesting-software/
ART: https://mecsoft.com/art-cam-software/
MESH: https://mecsoft.com/mesh/
